AT-S73 and AT-S99 Management Software User’s Guide
223
Displaying OAM Statistics
Note
These procedures require that the local and remote AT-CM Line
Cards be set to the OAM visible mode.
Menus
To display OAM statistics for local OAM clients from the menus:
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration Menu, shown in Figure 48
on page 128.
2. Select the AT-CM Line Card whose OAM statistics you want to view.
The Module Configuration Menu is shown in Figure 53 on page 139.
3. Select Port A to display the Port Management Menu in Figure 54 on
page 140.
4. From the Port Management Menu, select OAM Configurations to
display the OAM Configuration Menu in Figure 89 on page 204.
5. From the OAM Configuration Menu, select Show OAM Statistics to
display the Show OAM Statistics window in Figure 100.
Figure 100. Show OAM Statistics Window
Show OAM Statistics
Module 11, Port = A
Tx OAMPDUs 70917
Rx OAMPDUs 70918
Tx Information OAMPDUs 70917
Rx Information OAMPDUs 70918
Tx Event OAMPDUs 0
Rx Unique Event OAMPDUs 0
Rx Duplicate Event OAMPDUs 0
Tx Loopback Control OAMPDUs 0
Rx Loopback Control OAMPDUs 0
Tx Variable Request OAMPDUs 0
Rx Variable Request OAMPDUs 0
Tx Variable Response OAMPDUs 0
Rx Variable Response OAMPDUs 0
Tx Organizational Specific OAMPDUs 0
Rx Organizational Specific OAMPDUs 0
Rx Unsupported OAMPDUs 0
Return to OAM Configurations ...
