AT-S73 and AT-S99 Management Software User’s Guide
205
5. From the OAM Configuration Menu, select OAM Configuration to
display the OAM Configuration submenu, shown in Figure 90.
Figure 90. OAM Configuration Submenu
The parameters in the OAM Configuration submenu are defined in
Table 25. Your changes are immediately implemented by the line card.
OAM Configuration
Module 4, Port A
Admin State Enabled
Mode Passive
Maximum OAMPDU Size 1518
Unidirectional Support Yes
Loopback Support Yes
Link Event Support No
Variable Retrieval Support Yes
Return to OAM Configurations ...
Table 25. OAM Client Parameters
Parameter Description
Admin State This parameter controls the state of the OAM client on
the line card. The possible values are:
ˆ Enabled – This enables the OAM client. The line card
can participate in the OAM Discovery process and
perform other OAM functions. This is the appropriate
setting for the OAM-based features on the AT-CM
Line Cards. This is the default setting.
ˆ Disabled – This disables the OAM client. The line
card cannot participate in the OAM Discovery
process because it will not generate or respond to
OAMPDUs.
