AT-S73 and AT-S99 Management Software User’s Guide
183
2. To configure a remote line card, click the model name of its local line
card counterpart to display the Remote Module Status & Configuration
page, shown in Figure 79.
Figure 79. Remote Module Status & Configuration Page
Version This column displays the version numbers of the AT-S73
Management Software on the remote AT-CM Line Cards.
Link (A) This column displays the status of the remote peer
connections between the fiber optic ports on the local
and remote AT-CM Line Cards. The possible states are:
ˆ --: The fiber optic port on the local line card in the
managed chassis has not established a remote peer
management connection with the fiber optic port on
the remote line card.
ˆ Online: The fiber optic ports on the local and remote
line cards have established a remote peer
management connection.
ˆ No Support: The local line card does not support the
feature. Local AT-CM Line Cards display this state if
they are not configured for remote peer management
or if the remote device is something other than an
AT-CM Line Card. This status is also displayed by the
AT-CV5M02 Management Card and the AT-CV Line
Cards.
Table 21. Remote Module Status & Configuration Tab
Column Description
