AT-S73 and AT-S99 Management Software User’s Guide
123
Web Browser To view the operational information from the web browser windows:
1. Select Administrator from the menu bar.
2. Select the Diagnostics tab.
3. If the Chassis Diagnostics tab shown in Figure 47 is not selected,
select it. This window is for viewing purposes only. The information in
the window is described in Table 12 on page 122.
Flash
PROM This field displays the status of the Flash PROM on the
management card.
Serial
Interface This field displays the status of the Console port on the
management card.
RPSA and
RPSB This field displays the status of the power supplies and
fans, and the temperature and power voltage in the
AT-CV5000 Chassis. A status of “Not present” indicates
an empty power supply slot in the AT-CV5000 Chassis.
Neither the AT-CV1200 Chassis nor the AT-CV1203
Chassis display this information.
Table 12. Chassis Diagnostics Menu
Row Description
