AT-S73 and AT-S99 Management Software User’s Guide
115
Configuring the Temperature Threshold
The management card has a temperature threshold parameter to alert you
in the event the temperature of the wiring closet exceeds operating norms.
If the threshold is exceeded, the management card enters an event in the
event log and sends an SNMP trap. The temperature is measured on the
power supply near the cooling vents of the chassis and tends to reflect the
ambient air temperature.
Menus
To set the temperature threshold from the menus:
1. From the Main Menu, select Configuration to display the
Configuration Menu shown in Figure 20 on page 80.
2. From the Configuration Menu, select System Configuration to display
the menu in Figure 21 on page 80.
3. Select Temperature Threshold Configuration to display the
Temperature Threshold Configuration Menu in Figure 39. The
temperature threshold is given in Celsius (° C).
Figure 39. Temperature Threshold Configuration Menu
4. Select Maximum Temperature Threshold and enter a new value.
The range is 0 to 75° C. The default is 60° C.
5. To save your changes in the master configuration file, return to the
Configuration menu and select Save System and All Line Card
Configurations.
Web Browser
To set the temperature threshold from the web browser windows:
1. Select Configuration from the menu bar.
2. If the System tab is not selected, select it. The System tab is shown in
Figure 23 on page 83.
3. Click Edit in the Temperature Threshold section.
Temperature Threshold Configuration Menu
Converteon
Maximum Temperature Threshold: 60
Return to System Configuration Menu ...
