Chapter 5: Configuring AT-CM and AT-CV Media Converter Line Cards
130
IPC (Continued) C This is the total number of responses the management card is
waiting to receive from the AT-CM Line Cards.
For AT-CM Line Cards this column displays the following
information:
A This toggles to “*” when the management card is sending a
message to the line card in the slot.
B This toggles to “*” when the management card is waiting to
transmit a message to the line card.
C This displays the status of a line card’s response to the last
transmitted message from the management card. A successful
response is indicated by “*” while a bad response or no
response is signalled with “o”.
This column does not apply to the AT-CV Line Cards.
AC This column displays the status of the auto-copy feature for those
chassis slots that contain AT-CM Line Cards. For background
information, refer to “Configuration Files” on page 29. The possible
states are:
ˆ N for No - The auto-copy feature is not enabled on the slot. The
AT-CM Line Card uses its own configuration file to set its
parameter settings.
ˆ Y for Yes - The auto-copy feature is activated on the slot. The
configuration settings for the AT-CM Line Card in the slot are
provided by the management card from the master configuration
file.
The AT-CM70S Line Card and the AT-CV Line Cards do not support
the auto-copy feature.
VER This column displays the version numbers of the management
software programs on the AT-CV5M02 Management Card and the
AT-CM Line Cards. This field will be blank for AT-CM Line Cards that
have AT-S73 Management Software earlier than Version 3.0.0. This
field will also be blank for AT-CV Line Cards because they do not
have management software.
Table 13. Module Status and Configuration Menu
Column Description
000
C
B
A
