AT-S73 and AT-S99 Management Software User’s Guide

129

OperMode

This column displays different information depending on the type of
card. For the AT-CM and AT-CV Line Cards this column displays the
operating modes of the line cards. For background information, refer
to “Operating Modes” on page 42. The possible modes are:

ˆ

LinkTest - Link Test mode

ˆ

ML - MissingLink mode

ˆ

SML - Smart MissingLink mode

ˆ

OAM Visib - OAM Visible mode

ˆ

OAM Bypas - OAM Bypass mode

ˆ

LCMgmt - The operating mode is controlled by the card’s DIP
switches.

ˆ

Resetting - The line card is initializing its management software.
This state only applies to AT-CM Line Cards.

For the AT-CV5M02 Management Card this column displays the
card’s state. The possible states are:

ˆ

Active - The management card is in the active state.

ˆ

Standby - The management card is in the standby mode. This
state only applies to redundant AT-CV5M02 Management
Cards. For background information, refer to “Redundant
Management Cards” on page 26
.

IPC

This column displays utilization information of the backplane by the
management card and the AT-CM Line Cards. This information is
intended for manufacturing and test purposes.
For the AT-CV5M02 Management Card this column displays the
following information:

A

This is the slot number of the line card the management card is
currently polling. For example, the value “12” indicates that the
management card is polling the AT-CM Line Card in slot 12.
Slots that have AT-CV Line Cards are not polled by the
management card.

B

This is the total number of messages the management card is
waiting to transmit over the backplane to the AT-CM Line Cards.

Table 13. Module Status and Configuration Menu

Column

Description

1804

C

B

A
