Chapter 4: Configuring the AT-CV5M02 Management Card
80
Assigning an IP Address Configuration
This section explains how to assign an IP address, subnet mask and
default gateway to the management card. A management card can have
only one IP address configuration. The address can be assigned manually
or from a DHCP server on your network. For background information, refer
to “IP Address Configuration” on page 23.
Menus
To assign an IP address configuration to the card from the menus:
1. From the Main Menu, select Configuration to display the
Configuration Menu shown in Figure 20.
Figure 20. Configuration Menu
2. From the Configuration Menu, select System Configuration to
display the menu in Figure 21.
Figure 21. System Configuration Menu
Configuration Menu
System Configuration
Save System Configuration
Save All Line Card Configurations
Save System and All Line Card Configurations
Return System Configuration to Default
Configuration File Upload/Download with TFTP
Return to Main Menu ...
System Configuration Menu
System Name
System Clock Configuration
Omega Options
IP Parameters
SNMPv3 Configurations
TFTP Image Download Configuration
Terminal Configuration
Temperature Threshold Configuration
Return to Main Menu ...
