AT-S73 and AT-S99 Management Software User’s Guide
131
FIBER PORT or COPPER PORT
ST This column displays the states of the ports. The possible states are:
ˆ * - The port has establish a link to a network device.
ˆ o - The port has not establish a link to a network device.
SP This column displays the speeds of the ports. The possible speeds
are:
ˆ 10 - 10 Mbps
ˆ 100 - 100 Mbps
ˆ 1G - 1 Gbps
FC This column displays the status of flow control on the ports of the
AT-CM Line Cards. The possible states are:
ˆ Y - Flow control is enabled on the port.
ˆ N - Flow control is disabled on the port.
IngRL This column displays the settings of the ingress rate limiting filters
on the ports on the AT-CM Line Cards. The value “0” means rate
limiting has not been set on the port. This is the default setting. For
instructions on setting this parameter, refer to “Configuring the Port
Parameters on AT-CM Line Cards” on page 139. This feature is not
supported on the AT-CV Line Cards.
EgrRL This column displays the settings of the egress rate limiting filters on
the ports on the AT-CM Line Cards. The value “0” means rate
limiting has not been set on the port. This is the default setting. For
instructions on setting this parameter, refer to “Configuring the Port
Parameters on AT-CM Line Cards” on page 139. This feature is not
supported on the AT-CV Line Cards.
OAM This column applies only to AT-CM Line Cards operating in the OAM
visible or the OAM bypass mode. It displays the following OAM
client information:
Table 13. Module Status and Configuration Menu
Column Description
*00
C
B
A
