Chapter 5: Configuring AT-CM and AT-CV Media Converter Line Cards
140
3. Select the port you want to configure. You can configure only one port
at a time. This displays the Port Management Menu shown in
Figure 54.
Figure 54. Port Management Menu
Note
The OAM Configurations selection only applies to Port A on AT-CM
Line Cards set to the OAM visible mode or the OAM bypass mode.
Otherwise, the selection is hidden from view. The AT-CV Line Cards
do not support OAM.
Port This column identifies the port types.
Link This column displays the states of the links between the
ports and the network devices connected to the ports.
The possible states are:
ˆ Online: The port has established a link to a network
device.
ˆ Offline: The port is not connected to a network device
or has not established a link to a device.
Speed This column displays the current speeds of the ports, in
Mbps. For a port to display a speed, it has to be linked to
a network device.
Mode This column displays the duplex modes of the ports. For
a port to display a duplex mode, it has to be linked to a
network device. The possible duplex modes for the ports
are:
ˆ Full: Full-duplex mode.
ˆ Half: Half-duplex mode.
Table 15. Module Configuration Menu
Column Description
Port Management Menu
Module 4 - Port A
Port Configurations
OAM Configurations
Return to Module Configuration Menu...
