AT-S73 and AT-S99 Management Software User’s Guide
209
Performing an OAM Loopback Test
For background information, refer to “OAM Loopback Tests” on page 51.
Menus
To perform the OAM loopback test from the menus:
Caution
This test is disruptive to network operations. Some network traffic
may be lost. The local and remote media converter line cards do not
forward network traffic during the test.
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration Menu. An example of the
menu is shown in Figure 48 on page 128.
2. Select the local AT-CM Line Card you want to perform the loopback
test. This displays the Module Configuration Menu for the line card. An
example of the menu is shown in Figure 53 on page 139.
3. Select Port A to display the Port Management Menu, shown in Figure
54 on page 140.
4. From the Port Management Menu, select OAM Configurations to
display the OAM Configuration Menu in Figure 89 on page 204.
5. From the OAM Configuration Menu, select OAM Loopback Test to
display the OAM Loopback Test Menu, shown in Figure 92.
Figure 92. OAM Loopback Test Menu
OAM Loopback Test
Module 11, Port = 1
Enable Remote Loopback
> Disable Remote Loopback
Start Loopback Test
> Stop Loopback Test
Show Loopback Test Statistics
Clear Loopback Test Statistics
Return to OAM Configurations ...
