AT-S73 and AT-S99 Management Software User’s Guide
107
Configuring the 10/100Base-TX Port
The procedures in this section explain how to set the speed and duplex
mode on the 10/100Base-TX port on the AT-CV5M02 Management Card.
The management card uses this port to accomplish those management
functions that require communications with your network, such as sending
event messages to a syslog server or uploading or downloading files to a
TFTP server. For background information, refer to “10/100Base-TX Port”
on page 22.
Note
The port cannot be disabled. Additionally, the port’s wiring
configuration is preset to MDI and cannot be changed.
Menus
To configure the settings of the 10/100Base-TX port on the management
card from the menus:
1. From the Main Menu, select Module Status and Configuration.
2. Select the management card from the menu to display the Module
Configuration Menu shown in Figure 34.
Figure 34. Module Configuration Menu (Management Card)
Module Configuration Menu
Module 1
Module: AT-CV5M02
Port Link Speed Mode
A(100BaseTx) Online 100M Full
Module name
Reset CPM and Restart System Software
Return Management Card Port Configuration to Default
Return to Module Status and Configuration Menu...
