Chapter 4: Configuring the AT-CV5M02 Management Card
108
The columns in the Module Configuration Menu are described in
Table 10.
3. Select Port A (100Base-TX) to display the Port Configuration Menu
shown in Figure 35.
Figure 35. Port Configuration Menu for the 10/100Base-TX Port on the
Management Card
4. Configure the settings of the port as needed. To activate Auto-
Negotiation, select Auto negotiate. To set the speed and duplex
mode manually, select Manual negotiate to display the additional
parameters shown in Figure 36.
Table 10. Module Configuration Menu for a Management Card
Column Description
Port The port type is 10/100Base-TX.
Link The status of the link on the port. Possible values
are:
ˆ Online: The port has established a link to a
network device.
ˆ Offline: The port is not connected to a network
device or has not established a link to a device.
Speed The operating speed of the port. Possible values are
10M or 100M.
Mode The duplex mode of the port.
ˆ Full - The port is operating in full-duplex mode.
ˆ Half - The port is operating in half-duplex mode.
Port Configuration Menu
Module 1 - Port A (100Base-TX)
Link State: Online
> Auto negotiate
Manual negotiate
Return to Module Management Menu...
