Chapter 6: Configuring AT-CM Line Cards with Remote Peer Management
184
Note
You cannot disable the ports or change the operating modes or the
OAM settings on remote line cards.
Your changes to the settings on a remote line card are automatically
saved in the card’s configuration file in flash memory and are retained
even if the remote chassis is powered off or the card is removed from
the unit. For further information, refer to “Configuration Files” on
page 29.
3. When you finish configuring a remote line card, select Remote
Module Status & Configuration from the menu bar.
4. You can either select another remote line card to configure or continue
managing the local chassis.
Displaying the
Current
Configuration
To view the current parameter settings of a remote card:
1. Click the Line Card Configuration tab.
2. Click the Current Configuration tab. An example of the window is
shown in Figure 52 on page 137. The port parameters are described in
Table 16 on page 141 and the OAM parameters in Table 25 on
page 205.
Configuring
Remote Ports
To configure the parameter settings of a remote port:
1. From the Remote Module Status & Configuration window, adjust the
twisted pair port. You can configure only one port at a time.
2. Click the Port Configuration tab.
3. Configure the parameters, as necessary. The parameters are
described in Table 16 on page 141.
