AT-S73 and AT-S99 Management Software User’s Guide
157
Restoring the Last Saved Configuration
These procedures restore AT-CM Line Cards to their last saved
configurations. The configurations are obtained from the master
configuration file on the management card. You might perform this
procedure to discard parameter changes that you made to a line card but
did not save, or to configure a new line card with the save settings as its
predecessor in the chassis. For more information, refer to “Configuration
Files” on page 29.
This procedure is not applicable to the AT-CV Line Cards.
Caution
Restoring a line card to the last saved configuration may disrupt
network operations. Some traffic may be lost. A line card whose
current operating mode is different from its last saved configuration
has to initialize its management software after it receives the new
configuration from the management card. During the initialization
process, which takes approximately one minute, the line card
forwards network traffic using the default values for its parameter
settings.
Menus
To restore the last saved configuration of a line card from the menus:
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration menu shown in Figure 48
on page 128.
2. From the Module Status and Configuration menu, select the AT-CM
Line Card you want to configure. You can configure only one line card
at a time. The Module Configuration Menu in Figure 53 on page 139 is
displayed.
3. Select Line Card Configuration to display the menu in Figure 62 on
page 153.
4. To view the parameter settings of the card’s last saved configuration
before activating them on the line card, select Display Last Saved
Configuration.
5. To return the line card to its last saved configuration, return to the Line
Card Configuration menu and select Restore Last Saved
Configuration.
6. At the confirmation prompt, select Yes to restore the settings or No to
cancel the procedure.
