AT-S73 and AT-S99 Management Software User’s Guide
143
6. To save your changes in the master configuration file, return to the
Module Configuration Menu and select Line Card Configuration and
Save Line Card Configuration.
Web Browser
To configure the parameter settings of the ports on the AT-CM Line Cards
from the web browser windows:
1. Select Module Status & Configuration from the left menu bar.
2. In the Chassis View, click the line card port you want to configure.
Alternatively, select the Menu View tab and click the name of the line
card. You can configure only one line card at a time.
3. Click the Port A tab to configure the fiber optic port on the media
converter line card or the Port B tab to configure the twisted pair port.
You can configure only one port at a time.
Ingress Rate Limit
Egress Rate Limit (Continued) The Egress Rate Limit controls the number of bits per
second a port transmits to the network device connected to
it. Again, traffic that exceeds the limit is discarded before it is
transmitted by the port.
Port Statistics For information on this menu option, refer to “Displaying Port
Statistics” on page 160.
Table 16. Port Configuration Menu for Both Fiber Optic Ports and Twisted Pair Ports
Setting Description
