Chapter 4: Configuring the AT-CV5M02 Management Card
120
4. Select Data rate (baud rate) to display the Terminal Data Rate Menu
shown in Figure 44.
Figure 44. Terminal Data Rate Menu
5. From the Terminal Data Rate Menu, select the desired baud rate. The
default is 115200 bps.
Note
If you are managing the chassis from a local management session,
your session ends. To resume managing the chassis, change the
baud rate of your terminal or terminal emulator program.
6. To save your changes in the master configuration file, return to the
Configuration menu and select Save System and All Line Card
Configurations.
Web Browser
To set the baud rate of the Console port from the web browser windows:
1. Select Configuration from the menu bar.
2. If the System tab is not selected, select it. The System tab is shown in
Figure 23 on page 83.
3. Click Edit in the Terminal Setting section.
4. In the Terminal Setting pop-up window, select a new baud rate from
the pull down menu.
5. Click Update.
6. To save your changes in the master configuration file, select the Files
tab in the Configuration window and click Save System
Configuration and All Cards Configurations and Apply.
Terminal Data Rate Menu
Converteon
> 115200 bps
57600 bps
19200 bps
9600 bps
4800 bps
2400 bps
Return to Terminal Configuration Menu...
