AT-S73 and AT-S99 Management Software User’s Guide
283
Note
If you want to update the master configuration file before uploading it
to the TFTP server, click the radio button for Save System
Configuration and All Card Configurations and click Apply in the
Files tab.
3. In the Configuration File Upload section of the tab, select the TFTP
Server IP Address field and enter the IP address of the TFTP server
on your network.
4. Select the Configuration File Name field and enter a filename for the
configuration file. The file will be stored with this name on the TFTP
server. The extension should be “.cfg”.
5. Click Upload. The management card sends the its configuration file to
the TFTP server.
