AT-S73 and AT-S99 Management Software User’s Guide
151
Setting the Auto-copy Feature
These procedures set the auto-copy feature on the chassis slots that
contain AT-CM Line Cards. Auto-copy determines the source of the
configuration settings of a line card. A line card in a slot where this feature
is disabled use the configuration file in its own flash memory to set its
parameters whenever it is reset or powered on. In contrast, a line card in a
slot where this feature is enabled receives its configuration settings from
the management card on the master configuration file. For further
information, refer to “Configuration Files” on page 29.
Review the following before performing these procedures:
ˆ The auto-copy setting for a slot is stored in the master configuration file
on the management card. It is not stored in the configuration file in the
flash memory of a line card. Consequently, the AT-CM Line Cards do
not carry this setting with them when you install them in different slots
or chassis.
ˆ The auto-copy feature is not supported on the AT-CM70S Line Card or
the AT-CV Line Cards.
Menus
To set the auto-copy feature from the menus:
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration menu shown in Figure 48
on page 128.
2. From the Module Status and Configuration menu, select the AT-CM
Line Card you want to configure. You can configure only one line card
at a time. The Module Configuration Menu in Figure 53 on page 139 is
displayed.
3. Select Line Card Configuration to display the menu in Figure 62 on
page 153.
4. Select Auto-copy Line Card Configuration. The following prompt is
displayed.
Figure 60. Auto-copy Line Card Configuration Prompt
Display Current Configuration
Auto-copy enable
> Auto-copy disable
Return to Line Card Confirmation ...
