AT-S73 and AT-S99 Management Software User’s Guide
199
Configuring the T1/E1 Ports from the Console Port on the Line Card
This procedure explains how to configure the settings on the T1/E1 ports
on the AT-CM70S Line Card from the card’s Console port. This is the
appropriate procedure to perform when the card’s UART setting is set to
UART local console mode and the chassis containing the line card does
not have a management card.
Caution
The Console port on the AT-CM70S Line Card does not have any
security features like logon usernames or passwords. Anyone with
physical access to the location of the card may alter the
configuration settings of the T1/E1 ports on the device. The card and
its chassis should be installed in a secure location, such as a locked
wiring closet, to protect against unauthorized changes to its
operating parameters.
Note
The parameter settings of the SFP slot and the 10/100/1000Base-T
port on the line card cannot be set through the Console port.
To configure the T1/E1 ports from the Console port on the AT-CM70S Line
Card:
1. Configure the settings on your terminal or terminal emulator program
as follows:
ˆ Bits per second: 115200
ˆ Data bits: 8
ˆ Parity: None
ˆ Stop bits: 1
ˆ Flow control: None
ˆ Echo typed characters locally: Enabled
Note
The settings on the Console port on the line card are not adjustable.
2. Connect the management cable included with the AT-CM70S Line
Card to the Console port on the card and to the RS-232 port on your
terminal or computer.
3. If the card is already running, the terminal screen will be blank. To
display the card’s menu shown in Figure 88, type m for menu and
press Return.
