AT-S73 and AT-S99 Management Software User’s Guide
179
2. To configure a remote line card, select the card in the menu. This
displays the Remote Module Configuration Menu shown in Figure 77.
Figure 77. Remote Module Configuration Menu
The menu displays the current settings of the two ports on the remote
line card. The columns are described in Table 15 on page 139.
Note
You cannot disable ports or change the operating modes or the
OAM settings on remote line cards.
Your changes to the parameter settings on a remote line are
automatically saved in the card’s configuration file in flash memory.
They are retained even if the remote chassis is powered off or the card
is removed from the unit. For further information, refer to
“Configuration Files” on page 29.
3. When you finish configuring the remote line card, return to the Remote
Module Configuration Menu and select Return to Remote Module
Status and Configuration to display the Remote Module Status and
Configuration menu again.
Naming a Remote
Line Card
To assign a name to a remote line card:
1. From the Remote Module Configuration Menu, select the Module
Name field.
2. Enter a name of up to eight alphanumeric characters.
Remote Module Configuration Menu
Converteon
Module 1
Module: AT-CM202
Port Link Speed Mode
A(100BaseFX) Online 100M Full
B(100BaseTX) Online 100M Full
Module Name Module Name
Line Card Configuration
Return to Remote Module Status and Configuration ...
