Chapter 5: Configuring AT-CM and AT-CV Media Converter Line Cards
160
Displaying Port Statistics
Menus
To display traffic statistics for the ports on the AT-CM Line Cards from the
menus:
1. From the Main Menu, select Module Status and Configuration. The
Module Status and Configuration Menu is shown in Figure 48 on page
128.
2. Select the AT-CM Line Card whose statistics you want to view. An
example of the Module Configuration Menu is shown in Figure 53 on
page 139.
3. Select a port. You can select only one port. The Port Management
Menu is shown in Figure 54 on page 140.
4. Select Port Configuration. The Port Configuration Menu for the port
is shown in Figure 55 on page 141.
5. From the Port Management Menu, select Port Statistics. The
example Show Port Statistics window in Figure 66 is from the
AT-CM2KOS Line Card. All other AT-CM Line Cards have counters for
just CRC errors and collisions.
Figure 66. Show Port Statistics Window
The port statistics are described in Table 17.
Show Port Statistics
Module 14 - Port B
Received Packets 0
Transmitted Packets 0
CRC Errors 0
Collisions 0
Return to Port Statistics ...
Table 17. Port Statistics
Row Description
Received
Packets The number of packets received by the port from the
network device connected to it. This statistic is only
available on the AT-CM2KOS Line Card.
Transmitted
Packets The number of packets transmitted by the port. This
statistic is only available on the AT-CM2KOS Line Card.
