AT-S73 and AT-S99 Management Software User’s Guide
187
Displaying the Version Numbers of Remote AT-CM Line Cards
These procedures are used to view the version numbers of the AT-S73
Management Software and bootloader files on remote AT-CM Line Cards.
Note
This procedure requires that the local and remote line cards be
configured for remote peer management.
Menus
To view the information from the menus:
1. From the Main Menu, select Administration. The Administration
Menu is shown in Figure 28 on page 98.
2. From the Administration Menu, select Diagnostics to display the
Diagnostic Menu shown in Figure 45 on page 121.
3. From the Diagnostics Menu, select Remote Line Card Image
Version. An example of the Remote Line Card Module Software
Image Version window is shown in Figure 80. The information in this
window is for viewing purposes only.
Figure 80. Remote Line Card Module Software Image Version Window
Remote Line Card Module Software Image Version
Converteon
Module
App Ver.
BootLdr Ver.
1: AT-CV5M02
V3.0.0
2: Reg11
AT-CM202-v2
V3.0.0
V1.7.0
3: Reg20
AT-CM202-v2
V3.0.0
V1.7.0
4: Reg21
AT-CM202-v2
V3.0.0
V1.7.0
5: Area2a
AT-CM202-v2
V3.0.0
V1.7.0
6: Area2b
AT-CM212A/1
V3.0.0
V1.7.0
7: Reg12
AT-CM212A/1
V3.0.0
V1.7.0
8: Reg5
AT-CM212A/1
V3.0.0
V1.7.0
9: Reg17
AT-CM212A/1
V3.0.0
V1.7.0
10: --------
AT-CV102
--
11: --------
AT-CV102
--
12: --------
AT-CV102
--
13: --------
AT-CV102
--
14: --------
AT-CV102
--
15: Unequipped
--
16: Unequipped
--
17: Unequipped
--
18: Unequipped
--
Hit any key to continue ...
