AT-S73 and AT-S99 Management Software User’s Guide
139
Configuring the Port Parameters on AT-CM Line Cards
Note
The port settings on AT-CV Line Cards are not adjustable.
Menus
To configure the parameter settings on the ports on AT-CM Line Cards
from the menus:
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration menu, shown in Figure 48
on page 128.
2. From the Module Status and Configuration menu, select the AT-CM
Line Card you want to configure. You can configure only one line card
at a time. The current settings for the line card’s two ports are
displayed in the Module Configuration Menu. An example is shown
Figure 53.
Figure 53. Module Configuration Menu (Media Converter Line Card)
The columns in the table are defined in Table 15.
Table 15. Module Configuration Menu
Column Description
Module This field displays the model name of the line card.
Names of newer versions of the cards include suffixes,
like “v2.”
Module Configuration Menu
Converteon
Module 4
Module: AT-CM202-v2
Port Link Speed Mode
A(100BaseFX) Online 100M Full
B(100BaseTX) Online 100M Full
Module Name
Configure Operating Mode
Display DIP Switch Setting
Line Card Configuration
Return to Module Status and Configuration ...
