AT-S73 and AT-S99 Management Software User’s Guide
75
4. In the Module Status and Configuration Menu, examine the operating
mode of the line card in the OpMode column. If the line card is not set
to the OAM visible mode (OamVisib), you will have to set it to that
mode. For information about this menu, refer to “Displaying the Status
of the Line Cards” on page 128.)
Figure 19. Module Status and Configuration Menu
5. Select the AT-CM Line Card you want to configure and press Return to
display the Module Configuration Menu for the card.
Note
If the line card is already set to the OAM visible mode, go to step 11.
Otherwise, continue to the next step.
6. Select Configure Operating Mode to display the Operating Mode
Config Menu for the line card.
7. From the Operating Mode Config Menu, select OAM Visible Mode.
This confirmation prompt is displayed:
Warning: Changing the Operation Mode will reset the line
card.
Change Operation Mode now? (Yes or No):
8. Type Y to continue or N to cancel the procedure. This prompt is
displayed:
If auto-copy is enable, operation mode change need to be
saved to take affect.
Save line card configuration before rebooting? (Yes or
No):
Module Status and Configuration
Converteon
=================== MODULE INFO =================== ========= FIBER PORT ========== ========== COPPER PORT ==========
Mod_Name
CardTypeVer
ST OperMode
IPC
AC
VER
ST SP
FC IngRL
EgrRL
OAM
ST
SP
FC
IngRL EgrRL AN
