3. From the System Configuration Menu, select IP Parameters to display
the IP Parameters Menu shown in Figure 22.
Figure 22. IP Parameters Menu
4. To assign a static IP address configuration to the card, enter the
values in the IP address, Subnet mask, and Gateway address fields.
Here are the guidelines for assigning a static IP address configuration:
ˆ The values have to be entered in this format: xxx.xxx.xxx.xxx.
ˆ The DHCP client has to be disabled.
ˆ To delete a value without assigning a new value, enter 0.0.0.0.
ˆ The IP address configuration has to include a default gateway
address if the management card will be communicating with
network devices, like a TFTP server or syslog server, that are
located on a different subnet. This address should specify the first
hop to reaching the remote subnet and has to be a member of the
same subnet as the card’s IP address.
ˆ The default values are 10.0.0.1 for the IP address, 255.255.255.0
for the subnet mask, and 0.0.0.0 for the default gateway address.
5. If you want the card to obtain its IP address from a DHCP server on the
network, select Enable DHCP to activate the DHCP client. Or, to
deactivate the client to assign the IP address manually, select Disable
DHCP. The default setting for the client is disabled.
IP Parameters Menu
Converteon
IP address: 10.0.0.1
Subnet mask: 255.255.252.0
Gateway address: 0.0.0.0
Manager address: 0.0.0.0
Manager address: 0.0.0.0
Manager address: 0.0.0.0
Manager address: 0.0.0.0
Get community string: public
Set community string: private
Trap community string: public
Location: California USA
Contact: Allied Telesis
> Disable DHCP
Enable DHCP
Return to System Configuration Menu...
