Chapter 6: Configuring AT-CM Line Cards with Remote Peer Management
180
Displaying the
Current
Configuration
To view the current settings of a remote card:
1. Select Line Card Configuration.
2. From the Line Card Configuration menu, select Display Current
Configuration. An example of the window is shown in Figure 51 on
page 136. The port parameters are described in Table 16 on page 141
and the OAM parameters in Table 25 on page 205.
Configuring
Remote Ports
To configure the parameter settings of a port on a remote AT-CM Line
Card:
1. From the Remote Module Configuration Menu, select the port you
want to configure. You can configure only one port at a time.
2. Configure the parameters, as necessary. Refer to Table 16 on
page 141 for parameter descriptions.
Restoring the
Default Settings
To restore the default settings on a remote AT-CM Line Card:
Caution
This procedure may disrupt network operations. Some network
traffic may be lost.
Note
A remote line card that is returned to its default values continues to
support remote peer management because the default operating
mode for the AT-CM Line Cards is OAM visible.
1. From the Remote Module Configuration Menu, select Line Card
Configuration.
2. To view the default settings prior to activating them on the line card,
select Display Default Configuration. An example of the Display
Default Configuration window is shown in Figure 63 on page 154.
3. To return the parameter settings on the line card to the default values,
return to the Line Card Configuration Menu and select Return Line
Card to Default Configuration.
4. At the confirmation prompt, select Yes to return the parameter settings
on the line card to the default values or No to cancel the procedure.
