Chapter 9: Configuring AT-CM Line Cards for Dying Gasp
232
Figure 106. Line Card Module Software Image Version - AT-S73 Version
Numbers
6. Return to the Main Menu.
7. Select Module Status and Configuration.
8. In the Module Status and Configuration window, verify that the
operating mode of the line card is set to OAM visible mode
(OamVisib).
Figure 107. Module Status and Configuration Menu
9. Highlight the line card you want to configure and press Return to
display the Module Configuration Menu for the card. The menu is
shown in Figure 53 on page 139.
AT-S73 Management Software
Version Number
Line Card Module Software Image Version
Converteon
Module
App. Ver.
BootLdr Ver.
1: --------
AT-CV5M02
V3.0.0
V1.7.0
2: Reg11
AT-CM202-v2
V3.0.0
V1.7.0
3: Reg20
AT-CM202-v2
V3.0.0
V1.7.0
4: Reg21
AT-CM202
V3.0.0
V1.7.0
5: Area2a
AT-CM202
V3.0.0
V1.7.0
Line card operating modes
Module Status and Configuration
Converteon
=================== MODULE INFO =================== ========= FIBER PORT ========== ========== COPPER PORT ==========
Mod_Name
CardTypeVer ST OperMode
IPC AC
VER
ST SP
FC IngRL
EgrRL
OAM
ST
SP
FC
IngRL
EgrRL AN
1 ------
AT-CV5M02
*
-------
800
V300
-
---
-
----
----
---
*
100
-
----
----
-
2 Reg11
AT-CM202-v2 *
OamVisib
o** N
V300
*
100
N
0
0
A
*
100
N
0
0
Y
3 Reg20
AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
4 Reg21
AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
5 Area2a
AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
6 Area2b
AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
7 a121
AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
8 Reg12
AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
+oo
*
100
N
0
0
Y
9 AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
10 AT-CM202-v2 *
OamVisib
o*o N
V300
*
100
N
0
0
*oo
*
100
N
0
0
Y
11 AT-CV102
*
LinkTest
*
100
N
---
---
---
*
100
-
----
----
-
12 AT-CV102
*
LinkTest
*
100
N
---
---
---
*
100
-
----
----
-
13 AT-CV102
*
LinkTest
*
100
N
---
---
---
*
100
-
----
----
-
14 AT-CV102
*
LinkTest
*
100
N
---
---
---
*
100
-
----
----
-
15 AT-CV102
*
LinkTest
*
100
N
---
---
---
*
100
-
----
----
-
More ...
Return to Main Menu ...
