Chapter 5: Configuring AT-CM and AT-CV Media Converter Line Cards
166
Web Browser
To view the version numbers of the management software and bootloader
files on the line cards from the web browser windows:
1. Select Administration from the menu bar.
2. Select the Diagnostics tab.
3. Select the Linecard Image Information tab, shown in Figure 70. The
columns in the window are described in Table 18 on page 165.
Figure 70. Linecard Image Information Tab
BootLdr
Ver. This column displays the version numbers of the
bootloader files on the AT-CM Line Cards. This column
does not apply to the AT-CV5M02 Management Card
and the AT-CV Line Cards because they do not have
bootloader files.
Table 18. Line Card Module Software Image Version Window
Row Description
