AT-S73 and AT-S99 Management Software User’s Guide
233
Note
If the line card is already set to the OAM visible mode, go to step 11.
Otherwise, continue to the next step.
10. Select Configure Operating Mode to display the Operating Mode
Config Menu for the line card.
11. From the Operating Mode Config Menu, select OAM Visible Mode.
This confirmation prompt is displayed:
Warning: Changing the Operation Mode will reset the line
card.
Change Operation Mode now? (Yes or No):
12. Type Y. This prompt is displayed:
If auto-copy is enable, operation mode change need to be
saved to take affect.
Save line card configuration before rebooting? (Yes or
No):
13. Type Y for yes to update the master configuration file on the
management card with the new setting for the card’s operating mode.
This step is especially important if the auto-copy feature is activated on
the card’s slot. If the card’s operating mode isn’t saved in the master
configuration file, the new setting will not take affect because the card,
after resetting, will revert to its previous operating mode. If you are not
sure whether or not the auto-copy feature is enabled on the slot, select
Yes anyway. In fact, there is little likelihood you would ever respond
with No to this prompt. (This step isn’t applicable to the AT-CM70S
Line Card because it doesn’t support the auto-copy feature.)
The operating mode on the line card changes to OAM visible and the
card resets.
14. Wait approximately one minute for the line card to initialize its
management software and then select it again from the Module Status
and Configuration Menu:
15. From the Module Configuration Menu, select Port A, the fiber optic
port on the line card, to display the Port Management Menu, shown in
Figure 54 on page 140.
16. Select OAM Configurations to display the OAM Configuration menu,
shown in Figure 89 on page 204.
17. Select OAM Configuration to display the OAM Configuration
submenu, shown in Figure 90 on page 205.
18. If the Admin State is set to Disabled, select Admin State and press
Return to toggle the parameter to Enabled.
