AT-S73 and AT-S99 Management Software User’s Guide
165
3. From the Diagnostics Menu, select Line Card Image Version. An
example of the Line Card Module Software Image Version window is
shown in Figure 69. This window is for viewing purposes only.
Figure 69. Line Card Module Software Image Version Window
The columns in the window are described in Table 18.
Line Card Module Software Image Version
Converteon
Module
App Ver.
BootLdr Ver.
1: AT-CV5M02
V3.0.0
2: AT-CM202-v2
V3.0.0
V1.7.0
3: AT-CM202-v2
V3.0.0
V1.7.0
4: AT-CM202-v2
V3.0.0
V1.7.0
5: AT-CM202-v2
V3.0.0
V1.7.0
6: AT-CM212A/1
V3.0.0
V1.7.0
7: AT-CM212A/1
V3.0.0
V1.7.0
8: AT-CM212A/1
V3.0.0
V1.7.0
9: AT-CM212A/1
V3.0.0
V1.7.0
10: AT-CV102
--
11: AT-CV102
--
12: AT-CV102
--
13: AT-CV102
--
14: AT-CV102
--
15: (Not Inserted)
--
16: (Not Inserted)
--
17: (Not Inserted)
--
18: (Not Inserted)
--
Hit any key to continue ...
Table 18. Line Card Module Software Image Version Window
Row
Description
Module
This column displays the slot numbers and the model
names of the cards.
App Ver.
This column displays the version numbers of the
management software on the AT-CV5M02 Management
Card and the AT-CM Line Cards. This column does not
apply to the AT-CV Line Cards because they do not have
management software.
