Figure 73 an, Figure 74 – Allied Telesis AT-S99 User Manual
Page 171
AT-S73 and AT-S99 Management Software User’s Guide
171
Figure 73. SFP Information Window (1/2)
Figure 74. SFP Information Window (2/2)
SFP Information
Slot 4: Port A
Type of Serial Transceiver:
3 (Vendor Specific)
SONET Compliance Codes:
22
Gigabit Ethernet Compliance Codes:
2
Fiber Channel Link Length:
20
Fiber Channel Transmitter Type:
10
Fiber Channel Media Type:
1
Fiber Channel Speed:
15
Encoding:
5
Normal Baud Rate:
19 (2.5GHz)
9micro, Distance:
14
50micro, Distance:
0
60micro, Distance:
0
CU, Distance:
0
Transmit Disable:
1
Laser Fault:
1
Signal Detect (Logical 0)
0
Signal Detect (Logical 1)
1
Upper Baud Rate Margin (in %)
96
Lower Baud Rate Margin (in %)
8
Hit any key to continue ...
SFP Information
Slot 4: Port A
Vendor name (OUI)
LUMINENT
Vendor IEEE Company ID:
06b5
Vendor part number:
SFP-2500-SR1
Vendor revision number:
0000
Vendor serial number:
369G12O986
Vendor date code:
030609
Vendor specific ID:
Hit any key to continue ...
