AT-S73 and AT-S99 Management Software User’s Guide
221
Displaying OAM Information for Remote OAM Clients
The procedures in this section are used to view OAM status information on
remote OAM clients connected to local AT-CM Line Cards.
Note
These procedures require that the local and remote AT-CM Line
Cards be set to the OAM visible mode.
Menus
To display status information for remote OAM clients from the menus:
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration Menu, shown in Figure 48
on page 128.
2. Select the local card that is connected to the remote OAM device
whose status information you want to view. The Module Configuration
Menu is shown in Figure 53 on page 139.
3. Select Port A, the fiber optic port, to display the Port Management
Menu in Figure 54 on page 140. OAM is only supported on port A.
4. From the Port Management Menu, select OAM Configurations to
display the OAM Configuration Menu, shown in Figure 89 on page
204.
5. From the OAM Configuration Menu, select Show Remote OAM
Information to display the Show Remote OAM Information window,
shown in Figure 98.
Figure 98. Show Remote OAM Information Window
Show Remote OAM Information
Module 11, Port A
MAC Address 00:0c:46:9a:21:c9 Mux State Forward
Parser State Forward Local Discovering Yes
Local Stable No Remote Discovering No
Remote Stable No Critical Event No
Dying Gasp No Link Fault No
OAM Version 0x01 Config Revision 0x0003
Vendor Info 0x00160001 Vendor OUI 00-30-84
Mode Active Max OAMPDU Size 1518
Loopback Support Yes Event Support No
Variable Support Yes Unidirect Support Yes
Return to OAM Configurations ...
