Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

65

Drive Installation

Chapter 2

Figure 54 - Capacitor Cabinet

Grounding
Network

Line Capacitors

Motor Line

Capacitors

Cooling Fan
