26

Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

Chapter 1

Overview of Drive

Door Filter Blockage

Air Flow Restriction Trip / Warning

Storage and Transportation
Temperature Range

-40…70 °C (-40…185 °F)

Relative Humidity

Max. 95%, non-condensing

Altitude (Standard)

0…1000 m (0…3300 ft)

Altitude (Optional)

1001…5000 m (0…16,400 ft)

Seismic (UBC Rating)

1, 2, 3, 4

Standards

NEMA, IEC, CSA, UL, ANSI, IEEE

(1) Voltage Sag tolerance is reduced to -25% when control power is supplied from medium voltage via CPT.

(2) MOVs are used for 18 Pulse. Surge arrestors are used for AFE/Direct-to-Drive configurations.

(3) Short-circuit fault rating based on input protection device (contactor or circuit breaker).

(4) BIL rating based on altitudes < 1000 m (3300 ft) Refer to factory for derating on altitudes >1000 m.

(5) Optional.

(6) Under certain conditions, power system analysis will be required.

Table 1 - General Design Specifications (Continued)
