Internally mounted fans
Capacitor cabinets have internally mounted fans which are installed and wired by
Rockwell Automation (refer to
). The customer only needs to install the
fan hood.
Figure 46 - Fan Hood Installation (Internally Mounted Fans)
Fan Hood to be installed on site
Internally mounted fans
