302

Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

Chapter 5

Component Definition and Maintenance

Figure 251 - Converter PowerCage Module (Service – per Step 8)

Repeat this procedure for the lower manifold connection point. The chill
block can be extracted from the PowerCage per

Chill Block Removal and

Replacement on page 303

.

Figure 252 - Cooling System

Matched Set 2 SGCTs

Module Housing

Outlet Manifold

Clamp Base

Matched Set 2 SGCTs

Clamp Head

Inlet Manifold
