Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

63

Drive Installation

Chapter 2

Figure 52 - Converter Cabinet Components (4160V AFE shown)

Ground Bus

Isolated Gate Drive
Power Supplies
(IGDPS)

Inverter Modules

Rectifier Modules

Coolant Piping
