Figure 17, Figure 18 – Rockwell Automation 7000L PowerFlex Medium Voltage AC Drive (C-Frame) - ForGe Control User Manual
Page 41
Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014
41
Drive Installation
Chapter 2
Figure 17 - CPVC Pipe Splices (Capacitor #2 not shown for clarity)
Figure 18 - Typical Strap Wrench (not supplied) used to tighten unions on CPVC pipe splices
Pipe Splice #1
Capacitor
Cabinet
DC Link
Choke Cabinet
Pipe Splice #2
