44

Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

Chapter 2

Drive Installation

Figure 22 - DC Link Choke Cabinet after field connections of power bus

Figure 23 - Capacitor Cabinet after field connections of power bus

M-

M+

L+

L-

M+

L+

L-

M-
