Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

23

Overview of Drive

Chapter 1

Specifications

Table 1 - General Design Specifications

Description

Motor Type

Induction or Synchronous

Input Voltage Rating

2400V, 3300V, 4160V, 6600V

Input Voltage Tolerance

± 10% of Nominal

Voltage Sag

(1)

-30%

Control Power Loss Ride-through

5 Cycles (Std)
> 5 Cycles (Optional UPS)

Input Protection

(2)

Surge Arrestors (AFE/Direct-to-Drive)
Metal Oxide Varistor (MOV) (18 Pulse)

Input Frequency

50/60 Hz, +/- 0.2%

Power Bus Input Short-circuit
Current Withstand (2400…6600V

(3)

)

25 kA RMS SYM, 5 Cycle

Basic Impulse Level

(4)

45 kV (0…1000 m)

Power Bus Design

Copper - Tin plated

Ground Bus

Copper - Tin plated 6 x 51 mm (¼ x 2 in.)

Customer Control Wire Way

Separate and Isolated

Input Power Circuit Protection

(5)

Vacuum Contactor with Fused Isolating Switch
or Circuit Breaker

Output Voltage

0…2400V
0…3300V
0…4160V
0…6000V, 0…6300V, 0…6600V

Inverter Design

PWM

Inverter Switch

SGCT

Inverter Switch Failure Mode

Non-rupture, Non-arc

Inverter Switch Failure Rate (FIT)

100 per 1 Billion Hours Operation

Inverter Switch Cooling

Double Sided, Low Thermal Stress

Inverter Switching Frequency

420…440 Hz

Number of Inverter SGCTs

Voltage

SGCTs (per phase)

2400V
3300V
4160V
6600V

2
4
4
6

Inverter PIV Rating
(Peak Inverse Voltage)

Voltage

PIV (each device) Total PIV

2400V
3300V
4160V
6600V

6500V
6500V
6500V
6500V

6500V
13,000V
13,000V
19,500V

Rectifier Designs

Direct-to-Drive (transformerless AFE rectifier)
AFE with separate isolation transformer
18 Pulse with separate isolation transformer

Rectifier Switch

SCR (18 Pulse), SGCT (AFE Rectifier)

Rectifier Switch Failure Mode

Non-rupture, Non-arc

Rectifier Switch Failure Rate (FIT)

50 (SGCT) 100 (SCR) per 1 Billion Hours Operation
