DC FAIL:
Upon loss of DC output (V outputs
≤ 49 VDC) this output goes from low to
high.
Location
The AC/DC power supply is located in the low voltage panel in the far right-
hand section of the drive. A typical low voltage compartment is shown in
Figure 270 - Location of AC/DC Pioneer Power Supply on Low Voltage Panel
AC/DC Power Supplies
(Pioneer)
