Rockwell Automation 7000L PowerFlex Medium Voltage AC Drive (C-Frame) - ForGe Control User Manual
Page 168
168
Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014
Chapter 3
Operator Interface
Figure 178 - Key Slot Orientation
3.
Insert the card into the card slot and push until the card is firmly seated.
WARNING: Do not force the card into the slot. Forcing the card into the slot may
damage the connector pins.
KEY SLOT
