Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

287

Component Definition and Maintenance

Chapter 5

Converter Cabinet Components

Figure 236 - Converter Cabinet Components (4160V AFE shown)

Ground Bus

Isolated Gate Driver
Power Supplies
(IGDPS)

Inverter Modules

Rectifier Modules

Coolant Piping
