374

Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

Chapter 5

Component Definition and Maintenance

Downloading Firmware

Introduction

With the introduction of the PowerFlex 7000 Medium Voltage Drive, all drive
control functions are loaded on the Drive Processor Module (DPM) with
firmware via a serial connection on the Drive Processor Module data port J4. The
firmware is packaged into a single executable file (with the extension .exe).

This document describes how to download new or updated firmware to the drive
using the DPM data port. All firmware downloaded via this means is stored in
non-volatile Flash memory.

The latest firmware and the associated release notes are available on the Medium
Voltage intranet site, or can be obtained from Medium Voltage Product Support.

Overview

When the system is powered up, the drive executes the Application Code
contained in the on-board flash memory. If it does not have valid firmware, then
the entire system will drop into a download mode. In the download mode the
system is waiting to receive a firmware download via the serial data port J4 on the
DPM.

The system may also be placed into download mode from the Drive Terminal.
This can only be accomplished if you have obtained a minimum of
‘ADVANCED’ level access. Once that has been obtained, from the main screen
selecting UTILITY-TRANSFER-SYSTEM will place the drive into download
mode.

Ensure the parameters are saved to NVRAM, and saved to the Operator Interface
Terminal, and saved to any other external source such as the Flash Card,
DriveTools, or printed to a hardcopy.

TP34

DIAG_14

OIB C, RX3 Diagnostic Feedback

TP35

CMD_14

OIB C, TX3 Firing Command Signal

TP36

DIAG_15

OIB C, RX4 Diagnostic Feedback

TP37

CMD_15

OIB C, TX4 Firing Command Signal

TP38

DIAG_16

OIB C, RX5 Diagnostic Feedback

TP39

CMD_16

OIB C, TX5 Firing Command Signal

TP40

DIAG_17

OIB C, RX6 Diagnostic Feedback

TP41

CMD_17

OIB C, TX6 Firing Command Signal

TP42

TFB_C

OIB C Temperature Feedback Signal – There is no provision in the drive for the
use of this signal, it is only provided for Rockwell internal testing.

TP43

GND

Ground Reference for TP30 – TP42

Test Point

Signal Name

Description
