290

Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

Chapter 5

Component Definition and Maintenance

Figure 238 - 4-Device PowerCage

Figure 239 - 6-Device PowerCage

ATTENTION: The PowerCage can house either SCRs or Silicon Gate Commutated
Thyristors (SGCT). The SGCT circuit board is sensitive to static charges. It is
important that these boards should not be handled without proper grounding.

ATTENTION: Some circuit boards can be destroyed by static charges. Use of
damaged circuit boards may also damage related components. A grounding
wrist strap is recommended for handling sensitive circuit boards.

Matched Set 2 SGCTs

Module Housing

Outlet Manifold

Clamp Base

Matched Set 2 SGCTs

Clamp Head

Inlet Manifold

Matched Set 3 SGCTs

Module Housing

Outlet Manifold

Clamp Base

Matched Set 3 SGCTs

Clamp Head

Inlet Manifold
