Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

135

Operator Interface

Chapter 3

Store/Retrieve Configuration (NVRAM)

To access the memory functions, press [F5] on the Top Level Menu. Within this
screen it is possible to perform three operations on the memory of the drive. To
perform these operations you must have the proper access to the drive. Refer to
the section entitled

Enter/Modify an Access Level on page 116

.

Initialize

The drive contains a default set of parameters and setup information. This can
form a basis for configuring the drive. To initialize the drive with the default set of
data, press the [F3] key. The screen will appear as in

Figure 135

, indicating the

operation you are about to perform.

The screen then will ask you to confirm the operation. Press the [F8] key to
proceed, or the [F9] key to abort. Performing an initialization will overwrite the
data currently in the drive. Previous changes that were saved to NVRAM will not
be affected.

Figure 135 - Initialize Operation

Save

The changes that you have made to the drive data must be saved if you do not
want to lose the data when the drive is powered off. To save the changes, press the
[F5] key (

Figure 136

).
