Rockwell Automation 7000L PowerFlex Medium Voltage AC Drive (C-Frame) - ForGe Control User Manual
Page 396
396
Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014
Chapter 5
Component Definition and Maintenance
4.
From the Transfer menu, select Capture Text… as shown below.
Figure 340 - Capture Text
5.
The Capture Text dialog box will appear. Click on Browse button and
search the file Example.txt that you created in step 1 above.
Figure 341 - Open Text File
6.
Click Start.
HyperTerminal now acts as a dummy printer and is waiting for the
information to be transmitted from the drive to the laptop.
7.
From the drive Terminal, hit F3 (PRINT) at the main screen as shown
below:
Figure 342 - Terminal Screen
