Figure 49 – Rockwell Automation 7000L PowerFlex Medium Voltage AC Drive (C-Frame) - ForGe Control User Manual
Page 60
60
Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014
Chapter 2
Drive Installation
Figure 49 - Control and Cabling Cabinet (AFE Rectifier version shown) (with Control Panel
removed)
Hall-effect Sensor
Motor Terminals
Line Terminals
Voltage Sensing
Hall-effect Sensor
Surge Arrestors
Current
Transformer
