212

Rockwell Automation Publication 7000L-UM301D-EN-P - June 2014

Chapter 4

Commissioning

Figure 194 - Converter Cabinet Components (3300/4160V)

Ground Bus

Isolated Gate Drive
Power Supplies
(IGDPS)

Inverter Modules

Rectifier Modules

Coolant Piping
